What's Stonewall?

Stonewall occurs in a centrifugal compressor when the velocity of the gas in at least one stage reaches the speed of sound (Mach 1) at the gas conditions in that part of the machine. In a centrifugal compressor, this usually occurs near the eye of the impeller. When the velocity of the gas reaches Mach 1, the flow will no longer increase, regardless how much the pressure ratio drops across the stage.



impeller



Figure 1 - As the pressure ratio across a compressor stage drops, the flow increases. This increase in flow is accompanied by an increase in velocity throughout the compressor stage. The highest velocity is usually in the region just beyond the entrance to the blade path. When the velocity reaches Mach 1, the flow becomes choked, preventing any increase in flow with further drops in the pressure ratio across the stage.





Stonewall in a centrifugal compressor was once thought to be an insignificant event. This is no longer the case. Compressor manufacturers have found that prolonged operation of the compressor in stonewall can lead to fatigue failures of the impeller cover and blades. There is also an increase in the compressor discharge temperature due to the increase in entropy across the region of sonic velocity.

It is not always possible during the process design stage of a project to evaluate whether or not a compressor will be susceptible to stonewall operation just by reviewing the compressor characteristic curves and the process design data. A high fidelity dynamic simulation of the compressor and associated process can be very useful in determining whether or not a stonewall control system is warranted.



stonewall limit
Figure 2 - When the velocity of the gas reaches Mach 1 somewhere in the compressor, the flow will not increase as the head drops. The slopes of the characteristic lines become vertical when the head drops below the stonewall limit. This happens because the pressure information downstream of the region of sonic velocity cannot pass upstream to tell the upstream gas to pass more flow. This pressure information passes through the gas at the speed of sound, so when it reaches the region of sonic velocity, this lower pressure information in the downstream section hits an impasse.


There is an increase in the entropy as the gas passes through a region of sonic velocity, causing the discharge temperature to increase.







How can you prevent stonewall?
In general, the only way to prevent stonewall is to increase the pressure ratio across the compressor. This usually means a valve must be installed in the discharge that can be modulated to keep the compressor pressure ratio from dropping too much. The usual compressor control and protection schemes are not effective for preventing stonewall and adjustments to speed or recycle are usually ineffective in preventing stonewall. In order for a control system to be able to prevent operation in stonewall, the following are required:

1. A discharge flow control valve
2. Flow meter that measures the total flow through the compressor section
3. Suction and discharge pressure transmitters
4. Stonewall limit line prediction algorithm

The control system uses the suction flow and the pressure ratio to predict the location of the stonewall limit. As the stone wall limit is approached, the control system modulates the discharge control valve to prevent the pressure ratio from dropping any further.

Example Application
There are certain ethylene plant designs that include a side draw from the discharge of the third stage of a four-stage propylene refrigeration compressor (PRC). The gas extracted from the PRC is used for heat in a reboiler for the C2 splitter. If this flow is excessive, the third stage can be pushed into stonewall and the fourth stage can be driven into surge. All the flow through the fourth stage comes from the third stage and if the third stage is operated in stonewall, the discharge pressure of the third stage will drop significantly and consequently the fourth stage pressure ratio will increase significantly. This increase in the fourth stage pressure ratio will push the fourth stage back to its surge line, but no additional flow will be available for the fourth stage because it’s all passing through the side draw port of the third stage.

Stonewall blog post figure 3Figure 3 - In certain ethylene plant processes, some of the gas from the discharge of the third stage of the propylene refrigeration compressor (PRC) is extracted for heating of the C2 splitter reboiler. This gas is cooled by the reboiler and returned to the suction of the second or third stage of the PRC. If high flows are possible through this loop, it may be necessary to include a stonewall control valve that can restrict the amount of gas that is extracted from the discharge of the third stage.

Some of these PRC installations will include a recycle line (with
control valve) from the third stage discharge to the third stage suction. These valves are used to provide start up flow for the third stage when the reboiler is not ready to accept the heating gas from the third stage of the PRC.







Stonewall blog figure 4





Figure 4 - Similar to the technique used for preventing surge, a stonewall prediction algorithm is used to calculate the pressure ratio at which stone wall will occur for a given reduced flow. A setpoint is established that gives the stonewall controller an operating margin so that it can act in time to prevent excessive flow without acting too abruptly.
